RUGGEDJET 4230B

4-Inch Rugged Mobile Printer with Bluetooth® Wireless Technology

SKU: RJ-4230B

The RJ-4230B mobile label and receipt printer has the speed, durability, and Bluetooth® connectivity it takes to produce labels, tags, invoices, quotes, receipts, and more on the road. Because this model does not include a battery, it is the ideal solution for mounted use in public sector and field services vehicles using the optional battery eliminator. Print quickly and easily on the go – without the need for a network connection.

Battery not included.

Shipping Label being Printed by RuggedJet 4230B Series Mobile Printer

Real features

  • Print 2-inch to 4-inch labels, receipts, tags, and more at up to 5 inches per second print speed to increase efficiency
  • Stay printing amidst demanding applications or conditions with IP54 certification for dust and moisture, plus 6.88ft drop protection, reinforced parts, and molded rubber housing
  • Connect easily with USB Ver.2.0, Bluetooth® Ver. 4.2, MFi, and NFC pairing
  • Enable even greater mobility with optional accessories, including mounts and carrying cases, shoulder straps, belt clips, rechargeable Li-ion battery, in-vehicle DC adapter, 4-bay battery charger, and more
  • Windows®, Android, and Apple iOS® compatibility
  • Make remote updates and configuration easy with free Mobile Deploy app

In the box Printer, belt clip, support documents, roll holder stop
Dimensions 6.02in x 6.26in x 2.68in (153mm x 159mm x 68mm)
Weight Without battery: 1.58lbs (717g)
With battery: 1.87lbs (850g)
Memory 256MB DRAM / 64MB Flash
Control panel 1 LED with 4 buttons
Drop protection 6.9ft (2.1m), multiple drops, under controlled environment
Sealing certification IP54
Safety UL, CE, CSA
Operating temperature / humidity Battery: -4° F to 131° F (-20° C to 55° C)
AC adapter: 14° F to 104° F (-10° C to 40° C)
Car adapter: 14° F to 122° F (-10° C to 50° C)
Charging: 32° F to 104° F (0° C to 40° C), 10% to 90% non-condensing, max wet bulb: 80.6° F
Storage temperature / humidity -4° F to 140° F (-20° C to 60° C), 10% to 90% non-condensing, max wet bulb: 113° F (45° C)
Warranty 2 Year Premier Limited Warranty

Power 15V DC 4.0A
Battery Optional rechargeable Li-Ion smart battery: 7.2V, 3000mAh
Battery yield Up to 5360 (1in x 4in @ 7% black) labels per charge, under controlled environment with optional battery
Battery charging options AC adapter, car adapter
Battery charging time 4 hours with optional battery
Print technology Direct thermal
Resolution 203dpi
Max print speed Up to 5ips
Max print width 4.09in (104mm)
Max print length 118.1in (3m)

Communications interfaces USB, MFi, Bluetooth®, NFC
OS compatibility Windows®
For the most up-to-date compatibility, visit our Support Page
Print driver compatibility Windows® and Linux
For the most up-to-date compatibility, visit our Support Page
SDK support Android 6 or later iOS® 10 or later
Support software P-Touch Editor, P-Touch Transfer Express, Printer Setting Tool
Apps Print Service Plugin Support Center, PJ-673 Print, Print SDK Demo, RJ-4040 Print, Mobile Deploy, Mobile Transfer Express

Printer languages P-touch Template2.0, Raster, ESC/P
Emulations ZPL, CPCL (CPCL page print mode / CPCL line print mode)
Linear barcodes CODE 39, ITF (I-2/5) , EAN-8, EAN-13, UPC-A, UPC-E, UPC/EAN EXTENSION, CODABAR, CODE 128, GS1-128 (UCC / EAN 128), POSTNET, GS1 Databar (Omnidirectional / Truncated / Stacked / Stacked Omnidirectional / Limited / Expanded / Expanded Stacked), CODE93, MSI / Plessey, Intelligent Mail Barcode
2D barcodes QR Code (model 1, model 2, micro QR), Maxi Code, PDF417 (Standard, Truncate), MicroPDF 417, Data Matrix (Square, Rectangular), Aztec Code
Fonts ESC/P, P-touch Template: 3 BMP & 4 Outline Fonts
ZPL: 1 BMP & 1 Outline Font
CPCL: Standard Script, OCR-A, Unison, Manhattan, MICR, Warwick

Cutter Tear up & tear down bars
Media sensors Transmissive, reflective, continuous receipt, gap/black mark labels and tags, continuous linerless
Media type Paper and synthetic receipts, labels, and tags
Media loading Drop in roll
Media roll diameter 2.28in (58mm)
Media inner core diameter Receipt: 0.50in (12.7mm)
Label: 1.00in (25.4mm)
Media width 4.49in (114mm) max
Max media thickness Receipt: 2.3mil to 3.5mil (0.058mm to 0.089mm)
Tag: 3.5mil to 5.3mil (0.089mm to 0.135mm)
Label: 3.2mil to 6.7mil (0.081mm to 0.170mm)
